ROLL GRINDER, 36´´ x 300´´ TWO-WHEEL, FARREL (USED)
Sold
ROLL GRINDER, 36´´ x 300´´ TWO-WHEEL, FARREL (USED)
Description
Motors: Headstock 20 HP Wheel (2) 15 HP Traverse 3 HP Equipped With: Taper Grinding Crowning Compound Crowning Independent Drives to Each Wheel Acme Screw Infeed on Wheels with Heidenhain Feedback Scales Park Compumotor Spindle Drive Carriage Is Leadscrew Driven Machine was Reconditioned, Mechanical and Electrical in 1995
Specifications
| Manufacturer | Farrel |
| Condition | Used |
| Stock Number | VX-22836 |
| Maximum swing | 36" |
| Face grinding length | 300" |
| Wheel diameter | 20" |
| Maximum weight capacity | 40,000 Lbs. |
| Headstock speeds | 9.2 TO 27.6 RPM |
| Carriage feeds | 4.5 to 13.5 IPM / 14 TO 42 IPM |
| Overall dimensions (approx.) | 46' x 12' x 9' High |
| Approximate weight | 100,000 Lbs. |
| Note | Presently Set Up For Belt Grinding |
