DROP STACKER, RBI (USED)

DROP STACKER, RBI (USED)

orCall (734) 854-8700

Description

This Stacker provides excellent, tumble-free, straight and even stacks on large or small blanks Width and Lengths Adjustments are Both with Manual Controls Stacker mounts directly to the shear to conserve space and each part drops only inches on to the Stacking Table RBI Stack Table: The table is rated for 10,000 Lbs. at maximum of 144" The maximum Stack Height is 20" (Including Pallet Height) The Table produces excellent stacks because the feed system has the material stopped and aligned The Stack Table automatically lowers as material is cut

Specifications

ConditionUsed
Stock NumberVX-22966
Strip width12" Minimum to 60" Maximum
Thickness.020" Minimum to .070" Maximum
Maximum length144".
