36" x 7.00" x 20,000 Lbs. Wean Slitting Line

Manufacturer: Wean

Weight Capacity: 20,000lb

Coil ID: 20"

Coil Width: 36"

Line Speed: 250 FPM

Line Direction: Right to Left

Mandrel Uncoiler

-Hold Down Roll

-Hydraulic Expansion

-Slide Base

-Water Cooled Brake

Slitter Head

-7" Dia. Arbor x 42" Face

-Entry Pinch Roll

-Edge Guides

-AC Motor Threading Drive

Scrap Winder

-Hydraulic Oscillation

-Manual Scrap Ball Removal

McKay Flattener

-17 Rolls, 9 over 8

-Pull Thru

-Entry Separator Bar

Recoiler

-20" Dia. x 42" Face Drum

-Vertical Gripper

-Manual Grip and Expand

-Overarm Separator

-60 HP DC Motor, 300/1800 RPM, 240 V

Coil Car

-Self-Contained

-Hydraulic Lift and Travel

One-Arm Turnstile

-C-Hook Arm

-Hydraulic Push Off
