62" Pro Eco Aluminum Tension Leveling Line (Used)
Specifications
| Manufacturer | Pro-Eco |
| Condition | Used |
| Stock Number | VX-10249 |
| Maximum Entry Strip Width | 64.75" |
| Maximum Exit Strip Width | 62.5" |
| Maximum Strip Thickness | .063" |
| Maximum Incoming Coil O.D. | 103" |
| Maximum Incoming Coil Weight | 50,000 Lbs. |
| Width Tolerance, Over 60" | ±.06250" |
| Maximum Single Slit Width | 62.5" |
| Maximum Single Slit Thickness | .063" |
| Maximum Side Trim Width | 2.25" |
| 16" Uncoiler Mandrel Adjustment | +1.25" / -2.00" |
| 20"/24" Uncoiler Mandrel Adjustment | +.50" / -5.50" |
| 16" Recoiler Mandrel Adjustment | +0" / -.75" |
| 20"/24" Recoiler Mandrel Adjustment | ±.50" |
| Line Speed | 0 - 2,000 FPM |
Description
This used Pro-Eco Aluminum Tension Leveling Line offers robust performance for processing aluminum alloys with precision. Suitable for a range of strip widths between 29" to 64.75" on entry and 28" to 62.5" on exit, it manages strip thickness from .006" to .063". The line accommodates coils with an outer diameter up to 103" and weights reaching 50,000 lbs., ensuring versatility for various production needs. Engineered for high precision, it maintains width tolerances of ±.06250" for strips over 60" wide. The uncoiler and recoiler offer flexibility with adjustable mandrels, catered to both 16" and 20"/24" options, facilitating efficient material handling. The machine operates at speeds up to 2,000 FPM, with a tensioning capability supporting 1% elongation at a 58,000 PSI yield, ensuring reliable and consistent output quality. Upgraded in 2007 with new controls, this line is equipped for streamlined operation and ease of use. Its specifications make it a valuable asset for any industrial setup requiring dependable aluminum processing capabilities.
